Long Range Ultrasonic Level Sensor

IRU-3430

DESCRIPTION
Features

Long Range Ultrasonic Sensing

The IRU-3430 ultrasonic level sensor is built for long-range level measurement in challenging environments, offering a 50 ft. sensing range with a powerful transducer. Featuring AutoSense software, this sensor allows for quick and easy programming, adapting to various industrial level measurement applications.

Designed for hazardous environments, the CSA Class 1, Div. 2 certified IRU-3430 ensures safe and reliable performance. Its polycarbonate/PET blend housing, IP65 protection rating, and temperature compensation make it a durable choice for demanding applications.

Extended Range: 50 ft. ultrasonic sensing range with a high-power transducer
Certified for Safety: CSA Class 1, Div. 2 certified for hazardous environments
Smart Configuration: AutoSense software for customizable programming
High accuracy: ±0.25% of detected range
Fast response time: up to 50 Hz (every 20ms)
Durable housing: polycarbonate/PET blend with IP65 rating

Description
Additional information

IRU-3430 Datasheet

RST-3001 Setup Software

IRU-3430 User Manual

IRU-3430 Install Guide

RST-3002 Setup Software

Performance

Operating Range:
- 1.25 – 50 ft. (0.4 – 15.2 m) for liquid and solid targets
- 1.25 – 25 ft. (0.4 – 7.6 m) for bulk solids
Beam Pattern: 9º off axis
Internal Temperature Compensation: Yes
Frequency: 43 kHz
Accuracy: ±0.25% of detected range
Resolution: 0.1 in. (2.5 mm)
Response Time: Programmable (100 ms minimum @ 50 ft.)

Environmental

Enclosure Protection: IP65
Operating/Compensated Temperature Range: -20° to 140°F (-30° to 60°C)

Electrical

Total Current Draw: 75 mA @ 24 VDC
Operational Supply Voltage: 12-28 VDC
Programming Supply Voltage: 15-28 VDC
Wiring Connection:
- 3 or 5-conductor shielded cable
- 4 or 5-pin micro connector

Programming

Interface with RST-3002 Programmer (purchase separately)
- Interfaces with 32- and 64-bit operating systems
User selected units of measure

Connectivity

Output:
- 4-20 mA
- 4-20 mA with (2) NPN outputs

Physical

PC/PET housing
Transducer Type: Ceramic

Certifications

IP65
CSA:
- Inputs: 12 – 28 VDC; Outputs: 4-20 mA, NPN
Class I Division 2 Groups C & D T6 (Ta 60°C)
Ex nA IIB T6
Class I, Zone 2; AEx nA IIB T6

Is the IRU-3430 suitable for hazardous environments?

Yes, the IRU-3430 is CSA Class 1, Div. 2 certified, ensuring safe and reliable operation in hazardous locations with flammable gases, vapors, or liquids.

How does the AutoSense software improve sensor performance?

AutoSense software allows for quick and easy programming, automatically adapting to different level measurement applications to optimize accuracy and response time.

Can the sensor be used in extreme temperatures?

Yes, the IRU-3430 operates in temperatures ranging from -40°F to 140°F (-40°C to 60°C) and features temperature compensation for consistent performance in varying conditions.

What mounting options are available for the IRU-3430?

The sensor offers multiple mounting options, including 3” NPT and ¾” NPT threads, allowing for flexible installation in different industrial setups.

How durable is the IRU-3430?

The IRU-3430 is built with a polycarbonate/PET blend housing and features an IP65 protection rating, making it resistant to dust, water, and harsh environmental conditions.

What is the response time of the IRU-3430?

The IRU-3430 has a fast response time of up to 50 Hz (every 20 milliseconds), ensuring real-time level measurement and monitoring.

Can the IRU-3430 be integrated with remote monitoring systems?

Yes, the IRU-3430 can be connected to remote monitoring and control systems through its internet connectivity via the RST-5002 module, enabling real-time data access.

What applications is the IRU-3430 best suited for?

The IRU-3430 is ideal for industrial level measurement applications, including:

Tank level monitoring
Wastewater management
Chemical storage tanks
Silo and hopper level measurement
Remote sensing in hazardous environments

OUTPUT	4-20 mA
MOUNT	3", 3/4"
CERTIFICATION	CSA – General
RANGE	1' – 15', 1' – 25', 1' – 30', 1' – 50', 16' – 30', 31' – 50'
INDUSTRY	Chemical, Food & Beverage, Industrial Automation, Marine, Oil & Gas, Water & Wastewater
ENCLOSURE PROTECTION	IP65
